Teledyne Detcon 897-850000-316 Stainless steel junction box with solid cover

Description

What is the Teledyne Detcon 897-850000-316?

The Teledyne Detcon 897-850000-316 is: Stainless steel junction box with solid cover. The Teledyne Detcon Model DM-100 Series are compact toxic gas and oxygen sensors that deliver a 2-wire loop-powered 4-20 mA current signal equivalent to the sensor’s range of detection. The sensor is packaged in an electropolished 316 stainless steel housing with a 3/4 inch NPT thread, and its signal conditioning electronics are completely encapsulated for durability in harsh industrial environments. The plug-in, field-replaceable sensor cell uses large surface area gold-plated pins that reduce the effects of corrosion, and Teledyne lists cells for more than 25 gases including hydrogen sulfide, carbon monoxide, ammonia, chlorine, sulfur dioxide, and oxygen. Each sensor ships with a splash guard with integral calibration port, and options include aluminum or stainless steel upper enclosures with transient protection terminal board, a loop-powered digital display, and wireless communications. The Model 100 Series group in the Detcon price book lists 11 orderable part numbers; this is the stainless steel variant.

About the Teledyne Detcon Model 100 Series line

• Electrochemical plug-in sensor cells for 25+ toxic gases and oxygen, per the official gas list
• Output: 2-wire loop-powered 4-20 mA current signal
• Electropolished 316 stainless steel housing with 3/4 inch NPT thread; fully encapsulated electronics
• Plug-in, field-replaceable sensor cell with large surface area gold-plated pins
• Aluminum or stainless steel junction box options with transient protection terminal board
• Ships with splash guard with integral calibration port; loop-powered display and wireless communication accessories available

Where is it used?

Typical service: Fixed-point toxic gas monitoring in harsh industrial environments; Hazardous-area installations requiring simple 2-wire 4-20 mA loops; Oxygen deficiency and toxic gas leak monitoring around process equipment.

How do I order or get a quote?

PE Energy supplies the Teledyne Detcon 897-850000-316 on a quote basis: submit a request with your part number and application details and our team returns pricing and lead time. Detcon fixed gas detection is quoted rather than sold at list price because most items ship configured for gas type, range, and area classification. This part belongs to the same product line as the Model 100 toxic gas sensor we carry.
