Teledyne Detcon 897-860401-316 Mini 316SS junction box solid top

Description

What is the Teledyne Detcon 897-860401-316?

The Teledyne Detcon 897-860401-316 is: Mini 316SS junction box solid top. NEMA 7 rated condulet-style junction boxes in aluminum and 316 stainless steel used to mount and wire Teledyne Detcon fixed gas sensor assemblies, including the 700 series (FP-700, TP-700, IR-700) and Model 100 series, plus the RAM 700 remote alarm module. Sensors thread into a downward-facing 3/4 inch NPT female hub on the enclosure base. Covers are offered as solid (blank), glass lens (window), and extended lens versions so the sensor display remains visible. The Junction Boxes & Enclosures group in the Detcon price book lists 12 orderable part numbers; this is the 316 stainless steel variant.

Key specifications

• NEMA 7 rating for the standard aluminum and 316 stainless steel condulet enclosures
• Materials: copper-free aluminum or 316 stainless steel; base, cover, and bottom sections ordered separately
• Downward-facing 3/4 inch NPT female sensor connection; standard base has 3 ports
• Stainless steel junction box 12.5 in H x 6.1 in W x 4 in D; aluminum junction box 13 in H x 6.1 in W x 4 in D; mounting holes on 5.5 in centers
• Assembled weight approximately 6 lb with aluminum junction box and 9 lb with stainless steel junction box (FP-700 sensor assembly)
• NEMA 4X expansion enclosure available for Model 1000 series analyzer option boards

Where is it used?

Typical service: Hazardous-area field wiring and mounting of Detcon fixed gas sensors; Display visibility and magnetic programming access through glass lens covers; Housing expansion option boards for Detcon analyzer systems.

How do I order or get a quote?

PE Energy supplies the Teledyne Detcon 897-860401-316 on a quote basis: submit a request with your part number and application details and our team returns pricing and lead time. Detcon fixed gas detection is quoted rather than sold at list price because most items ship configured for gas type, range, and area classification.
